Procedure
E-2 Data Export - Installation on the Database Server
Procedure
The procedures for installing the Data Export feature are described in the following sections.
• Installing the NIC (if needed).
• Entering customer specified IP Address on the NIC.
• Enter the Host Name of Holter or 12-Lead ECG Management System in the Network
Configuration (via !Config Wizard)
• Testing exporting patient ECG data via the hospital’s LAN to the receiving system.
Note If your system already has the Web Option installed, the 2nd NIC is already installed then you
don’t need to install another NIC for the Data Export feature.
Installing
the 2nd NIC
Card
These options includes a second Network Interface Card (NIC) that must first be installed in
the rear of the Database Server. The following steps describe how to install this card.
Step 1. Shutdown the Database Sever using the Shutdown Normal application in the
Shutdown menu of the Service window.
Step 2. Turn off the power to the Database Server and remove the power cord from its AC
receptacle.
Caution When opening the Database Server and handling the NIC (or any PC board), follow all
proper ESD protection guidelines, including grounding the Database Server, the work
surface, and yourself.
Step 3. Remove the front bezel and left side panel cover (Cover 1) of the Database Server.
Lay the unit on its side to facilitate PC board installation.
Note Procedures for Removing and Replacing Covers on the Database Server are given in the
ML370 Installation Guide.
Step 4. Remove the I/O board clamp holding the PC boards in place.
Step 5. Insert the NIC into Slot 6 on the rear of the Database Server. Assure that the card is
securely connected to the backplane. See Figure E-1 on the following page.
Step 6. Secure the NIC to the backplane with the screw provided.
Note All cards in the backplane should be secured by a screw. If any are not, secure them with a
screw.
Step 7. Reinstall the I/O board clamp.
To Next Page
