Site Preparation
Site Planning and Preparation
4-23
Electrical
Requirements
The following table gives electrical requirements for the Information Center installations
shown in Figure 4-9. To determine similar specifications for Information Center installations
different from those in Figure 4-9, consult Table 4-5 and/or the documentation for the units
that comprise the system.
Network
Connection
The Information Center computer obtains its information from patient monitors connected to
the Serial Distribution Network (SDN) through the System Communications Controller
(SCC). Therefore, an SDN wall box connection to the SCC should be installed near where the
Information Center computer will be located.
Procedures for installing SDN wall boxes and cabling are described in detail in the CMS Site
Preparation and Installation Manual. Refer to that manual for installing SDN wall box
connections. For available SDN installation material options, see M3199AI Options using
UTP Cable.
Clinical Network cabling, wall boxes, and faceplates are generally the responsibility of a
certified cabling installer. However, the network design should give careful consideration to
the locations of RJ-45 wall boxes, both for the clinical equipment -- Information Centers,
Clients, printers -- and for the active Network components that require them. Distances
between wall boxes and the devices that connect to them will depend on the lengths of RJ-45
and other types of cable.
Network
Card and
TCP/IP
Settings
The following features of the Information Center software require a second Network interface
card (NIC) to be installed (refer to Chapter 2 Hardware Description):
• 12-Lead Export
•Holter Export
• HL7 Export
• Web Access
• Patient Data Transfer
The settings required for this NIC card are for connection to the hospital network and are site-
specific. These settings will be entered into the Control Panel during hardware installation.
Physical network connections including cable runs and wall boxes must also be considered.
Connection to the Hospital LAN requires a 100 Mbit connection.
Table 4-5. Electrical Requirements for Information Center Installations
System
Input Voltage
(VAC)
Input
Frequency (Hz)
Manual
Switching
Required?
Input Power
(max) (Watts)
Notes
A 110 - 127 UPS: 50/60
All others: 50-60
PC & UPS: yes
All others: no
858 Assumes single,
medium display, PC,
Recorder, and UPS.
220 - 240
B 110 - 127 UPS: 50/60
All others: 50-60
PC & UPS: yes
All others: no
958 Assumes dual,
medium displays, PC,
Recorder, and UPS.
220 - 240
C 110 - 127 UPS: 50/60
All others: 50-60
PC & UPS: yes
All others: no
858 Assumes single,
medium display, PC,
Recorder, and UPS
220 - 240
