Components and Options
1-48 Introducing the IntelliVue Information Center System
Clinical
Network
Active
Components
Clinical Network active components are ordered under Product # M3185A
Cabling
Installation
Materials
Cabling installation materials are ordered under Product # M3199AI.
Table 1-27. Active Components for M3185 Clinical Network
Option Description
C01 Core Switch
C02 Edge Switch
C03 Extension Switch
C05 10 Mbit/s UTP repeater
C07 100-FX SC Transceiver (Fiber Port) for the Core and Edge Switches
C10 10 Mbit/s media translator pair
C11 100 Mbit/s media translator
C21 Wireless Access Point
C36 Harmony Access Point Controller
C37 Harmony Access Point
C38 Harmony Remote Power Supply
C39 Harmony Access Point over LAN Module
C41 Bedside Wireless Adapter
Table 1-28. M3199AI Passive Components for M3185 Clinical Network
Option Description
UTP Cable
P01 305 m (1000 ft.) Unshielded Twisted Pair (UTP) plenum cable (Cat. 5,
Orange)
Patch Cables
J10 0.9 m (3 ft.) UTP Patch Cable
J11 2 m (7 ft.) UTP Patch Cable
J12 3.7 m (12 ft.) UTP Patch Cable
J20 3.7 m (12 ft.) UTP Crossover Cable
J21 0.9 m (3 ft.) UTP Crossover Cable
J30 3.0 m (9.8 ft.) Fiber Optic Patch Cable - ST/ST
J31 3.0 m (9.8 ft.) Fiber Optic Patch Cable - SC/SC
J32 3.0 m (9.8 ft.) Fiber Optic Patch Cable - ST/SC
Access Point Antenna Extensions
A20 0.9 m (3 ft.) Access Point antenna extension
A21 3.0 m (10 ft.) Access Point antenna extension
Patch Panel Kits
A01 24-Port Patch Panel Kit
A05 Patch Panel Wall Mount Kit
Wall Mount Kits
A10 Dual Port, single gang, RJ-45 UTP Wall Box Kit (US only)
A11 Dual Port, single gang, RJ-45 UTP Surface Mount Kit
A12 Quad Port, dual gang, RJ-45 UTP Wall Box Kit (US only)
A13 Quad Port, dual gang, RJ-45 UTP Surface Mount Kit
