Specifications
2-52 Hardware Description
Note The ECG aspect ratio and 25 mm/s + 10% specifications are likely to be met with a high
quality display and video cable that satisfies the specifications recommended in Table 2-7.
Some displays have visible and/or protruding menu keys that can interfere with the operation
of the Application software. Verify when installing customer supplied displays that these
buttons are protected from the possibility of interference.
Flat Panel
Specifications
A small number of missing pixels is normal for flat panel (LCD) displays and is not an
indication that the display is not meeting specifications and needs to be replaced. The
following specifications for the M3163-60001 flat panel display are listed here:
Monitor Backlight (Brightness)
• Working Conditions
– Ambient temperature: 25 +/- 5 degrees C
– Brightness control (Vvr4): 0V
• Definition of defect
– Brightness falls under 50% of the minimum brightness value of the flat panel
display (Minimum brightness 210 cd/m2)
– The lamp does not turn on
– The lamp starts flashing
Inspection Specifications for Pixel Drop Out
• Area to be inspected
– Inside display dot area (345.6 x 276.48 mm) - display dot area is the “active area”
– One pixel consists of 3 dots (red, green and blue)
• Bright pixels definition
– Bright pixels are classified as follows (based on luminance samples)
Viewable width of 1280 dots Note—This value is the Visible Display Width that is entered in the
Config Wizard Device Setup and Support Information Screen. The valid
range is 267 to 1188 mm.
Some typical values include:
• M3161 (medium) CRT Display: 308 mm
• M3162 (large) CRT Display: 381 mm
• 862100 Medium Flat Panel Display: 338 mm
• 862428 Medium Touch Flat Panel Display: 338 mm
• 862103 Large Flat Panel Display: 359
Red, Green, & Blue Video Inputs ~ 0.7 V
p-p
Vertical & Horizontal Multi-Sync Inputs 5 V
TTL
Video Cable Connector HD 15 Male
Color Depth 24-bit (or greater) True Color
Table 2-7. Recommended Display Specifications for Information Center Displays
Specification Value
