Mounting
2-32 Hardware Description
The processing unit and UPS system mounts can be combined for a single wall mount
installation as shown in Figure 2-34. Note that the installation can be mounted either
vertically or horizontally, depending on the space available.
Figure 2-34 Combined Wall Mount Options
A table of optional mounting hardware is given in Chapter 1, Mounting Options. Detailed
installation notes are provided with each mounting hardware option that describe its assembly
and installation, and also copies are contained on the Information Center Service
Documentation CD-ROM supplied with your Service Kit.
Horizontal Mount
UPS
Vertical Mount
UPS
PC
