Configuration
6-38 Software Installation & Configuration
configured with a Monitor Label. The Mx/IntelliVue patient monitors, their associated Bed
Label, and the Information Center that receives their patient data are displayed.
Note For hardwired monitors, Bed Label and Equipment Label will be the same.
For telemetry monitors, Bed Label and Equipment Label will be different because
telemetry monitors can be reassigned by the user to different beds.
Buttons to the right of the Equipment setup for the selected SCC field are for making
Bed Label and monitoring Equipment assignments.
Field Description
LBN The Logical Branch Numbers (1-24) of the SDN branches on the SCC for patient monitors
Bed Label Label assigned to the patient bed for the monitoring equipment attached to that LBN.
If an entry has an equipment Label but no Bed Label, then it has been entered as unassigned for
monitoring equipment that can be assigned during monitoring with the Sector Setup
application
Equipment Label assigned to the monitoring equipment attached to that LBN.
Type Indicates whether the monitoring equipment is a hardwired bedside monitor or a mobile
telemetry monitor.
Monitored by Host Name given to the Information Center that monitors the equipment connected to the SCC
selected. Host Names are displayed in Purchased Options and Support Information.
# of Clients The # of Information Center Clients that have selected the Monitored by Information Center for
overviewing patent data.
Button Description
