Topologies
Introducing the IntelliVue Information Center System
1-11
3
Native only
4
Served by the Application Server
5
Single or multiple M3154 Database Servers
6
Across multiple M3154 Database Servers
Figure 1-7 Typical Basic System Topology
128 patients
(max)
100 Mbit/s
10 Mbit/s
HIS LAN for
web access
100 Mbit/s
Wired
IntelliVue Patient Monitor
18.5
IntelliVue Clinical Network
M2385 Application Server
100 Mbit/s
18.5
M3154
Database Server
HIS LAN for
web access
16 patients
M3151
LaserJet Printers
16 patients
16 patients
Clients
16 patients
M3151
Clients
M3155
M3155
Network Switch
Information
Center
Information
Center
10 Mbit/s
16 patients
100 Mbit/s
