Troubleshooting
7-92 Maintenance, Troubleshooting, and Repair
Lead MCL2 150 - 350 150 - 350 H0 - H9
Lead MCL3 150 - 350 150 - 350 J0 - J9
Lead MCL4 150 - 350 150 - 350 K0 - K9
Lead MCL5 150 - 350 150 - 350 L0 - L9
Lead MCL6 150 - 350 150 - 350 M0 - M9
Lead MCL 150 - 350 150 - 350 N0 - N9
Single Auto N/A N/A 150 01
Manual Lead I 150 - 350 150 - 350 P0 - P9
Lead II 150 - 350 150 - 350 R0 - R9
Lead III 150 - 350 150 - 350 S0 - S9
Lead AVR 150 - 350 150 - 350 T0 - T9
Lead AVL 150 - 350 150 - 350 V0 - V9
Lead AVF 150 - 350 150 - 350 W0 - W9
Lead V1 150 - 350 150 - 350 X0 - X9
Lead V2 150 - 350 150 - 350 Y0 - Y9
Lead V3 150 - 350 150 - 350 Z0 - Z9
Lead V4 150 - 350 150 - 350 b0 - b9
Lead V5 150 - 350 150 - 350 c0 - c9
Lead V6 150 - 350 150 - 350 d0 - d9
Lead V 150 - 350 150 - 350 f0 - f9
Lead MCL1 150 - 350 150 - 350 g0 - g9
Lead MCL2 150 - 350 150 - 350 h0 - h9
Lead MCL3 150 - 350 150 - 350 j0 - j9
Lead MCL4 150 - 350 150 - 350 k0 - k9
Lead MCL5 150 - 350 150 - 350 m0 - m9
Lead MCL6 150 - 350 150 - 350 n0 - n9
Lead MCL 150 - 350 150 - 350 p0 - p9
a. User specified lead is not active
Classification Mode Detection Mode
User Specified
Detection Lead
User Specified
Detection Threshold
Algorithm Minimum
Detection
Threshold
Third and Fourth
Character
