202 ProSYS Installation and Programming Manual
Dimensions
9.0 cm x 9.0 cm x 6.7 cm
3A Switched Power Supply Expansion Module
Input Power
16.5VAC @ 50VA (via 230VAC/16.5VAC/50Hz transformer).
Rechargeable Standby
Battery
12V Up To 21 Amp-Hours (AH)
Power Outputs:
Bell/LS (External)
Auxiliary Output: 3A @13VDC
Bell/LS (External) Sounder Output: 1.7A @13VDC
Overload Protection: Automatic Electronic Protection
On board utility Outputs
2 relays, 12VDC @ 3A max Dry Contact Relays
Main Panel Connection
4-wire BUS, up to 300 m from Main Panel
Dimensions
90mm x110mm x 30mm
Event Log Expansion Module
Current Consumption
30 mA maximum
Main Panel Connection
4-wire BUS, up to 300 m from Main Panel
Dimensions
10.5 cm x 6.6 cm x 1.8 cm
Printer Module
Current Consumption
10 mA, maximum
Main Panel Connection
4-wire BUS, up to 300 m from Main Panel
Dimensions
6.2 cm x 5.3 cm x 1.6 cm
X-10 Transmitter Module
Current Consumption
30 mA maximum
Main Panel Connection
4-wire BUS, up to 300 m from Main Panel
Dimensions
10.5 cm x 6.6 cm x 1.8 cm
Access Control Module
Input Power
13.8V DC + 10%
Current Consumption
100 mA maximum
Main Panel Connection
4-wire BUS RS-485, up to 300 m from the Main Panel
Readers Consumption
5V / 150 mA maximum
Dimensions
16.5 cm x 8.8 cm x 2.1 cm
Relay
24V DC / 1 A maximum
Advanced Voice Module
Current Consumption
(standby/active speaking)
38 mA / 60 mA
Audio Signal
Max = 5Vpp / Max = 2V
Dimensions
16.5 cm x 6.6 cm x 1.8 cm
