Note
Status of BATCH recipe objects (RUP, ROP, RPH, and transition)
Information on the status of recipe objects is provided in the section "Allocation statuses of
batch steps (Page 432)".
Shortcut menu and toolbar for selected objects in the navigation area
The shortcut menu and toolbar contain operating commands for recipe step processing of
active batches for each selected object in the navigation area. On both the shortcut menu and
the toolbar, only commands that can be used for the specific use are offered.
Icon on toolbar or
shortcut menu
Command Meaning
Dock/Undock Undock: The OS control is detached from the process picture
and can be resized and positioned anywhere in the workspace.
Dock: The relevant undocked OS control is reinserted at its
original position in the process picture.
Undock automati‐
cally
When you use this command for the corresponding OS con‐
trol, the OS control is opened and positioned automatically in
the workspace each time it is used. This means that for certain
types of operator input in one OS control, another correspond‐
ing OS control is opened automatically.
Change When you click the "Change" command, a drop-down list
opens with additional commands.
Use the listed commands to change to the respective OS con‐
trol. If you have activated the command "Undock automatical‐
ly" in the target OS control, the OS control will be displayed in
undock state at that location in the workspace where it was
saved last.
The drop-down list will always offer the change into all OS
controls, except for the change into itself or to the OS Control
Monitor.
New batch(es) Creates new batches in the display area of the OS Control
Creation based on a selected batch. In the case of multiple
selection, the data from the batch that was first selected is
always used as the template data.
Delete batch Permanently deletes the selected batch following your confir‐
mation.
Release batch Releases the selected batch following your confirmation.
Cancel batch Cancels the selected and released batch following your con‐
firmation.
Lock batch Disables the selected and released batch following your con‐
firmation. You can recognize a locked batch by the "Locked
batch" symbol.
Unlock Enables a selected and previously disabled batch.
Start batch Starts the selected and released batch following your confir‐
mation.
BATCH OS controls
11.3 Operations in process mode
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 615
