Strasbaugh nTellect (Model 7AF) Wafer Grinder
8 - 10 Version 1.2 - June 2004
Choices Available at the Home Machine Menu
Buttons,
Submenus and
Icons
Functions
QUIT
Touch the QUIT button to return to the Main Menu.
Home
All
Touch the Home All button to automatically home the robot, pre-
aligner, coarse spindle z-axis, fine spindle z-axis, and bridge. The
Home All function must be performed each time the machine is
turned on.
During homing a "homing" message will appear above the icon of
the component being homed. When a component has been
homed, a "homed" message will appear above its icon.
Robot
Prealigner
Coarse
Spindle
Fine
Spindle
Bridge
Touch the Robot icon to individually home the robot.
Touch the Prealigner icon to individually home the pre-aligner.
Touch the Coarse Spindle icon to individually home the coarse
spindle z-axis.
Touch the Fine Spindle icon to individually home the fine spindle
z-axis.
Touch the Bridge icon to individually home the bridge.
Reference
Chucks
Left
Both
Right
Cancel
Touch the Reference Chucks button to display the Reference
Chucks submenu, shown immediately below, at which you may
select the chuck(s) to reference.
Touch the Left button to reference the left work chuck.
Touch the Both button to reference both work chucks.
Touch the Right button to reference the right work chuck.
Touch the Cancel button to close the Reference Chucks submenu.
Note: If the chucks are to be referenced immediately after
homing, you must "quit" to the Main Menu and then return to the
Home Machine menu to select the Reference Chucks button.
