STRASBAUGH, INC.
6-24 February 19, 2002 7AF SECS/GEM Interface Ver. 1.9
Strasbaugh Confidential
6.51 S5F3 - Enable/Disable Alarm Send
S5F3 [W] * H->E
<L [2]
<B [1] ALED> * ALED - Alarm Enable/Disable Code
<U4 ALID> * ALID - Alarm ID
> .
The Host commands the Equipment to enable or disable (depending on ALED) reporting for the specified Alarm ID in
S5F1, S5F8, S5F71, and S5F73.
ALED Description
0x80 Enable sending alarm.
0x00 Disable sending alarm.
The following special format can be used to enable or disable all ALIDs.
S5F3 [W] * H->E
<L [2]
<B [1] ALED> * ALED - Alarm Enable/Disable
Code
<U4> * ALID - Alarm ID
> .
The Host may optionally set the W-Bit to "1" in S5F3. If so, the 7AF replies with S5F4.
6.52 S5F4 - Enable/Disable Alarm Acknowledge
S5F4 * H<-E
<B [1] ACKC5> . * ACKC5 - Acknowledge Code
ACKC5 Description
0x00 Normal. Everything Correct
0x01 Invalid ALID.
6.53 S5F5 - List Alarms Request
S5F5 W * H->E
<U4 ALID ...> . * Alarm ID Array
The Host requests the Equipment to send the current status of the specified Alarm IDs.
The Host can use the following special format to request the status of all Alarm IDs:
S5F5 W
<U4>. * ALID
