Strasbaugh nTellect (Model 7AF) Wafer Grinder
8 - 20 Version 1.2 - June 2004
Choices Available at the Dress Cycle Menu
Buttons,
Submenus,
and Icons
Functions
QUIT
Touch the QUIT button to return to the Main Menu.
Grind Chuck
Left
Right
Cancel
Truing
Dressing
Cancel
Touch the Grind Chuck button to display the Select Chuck and
Select Grind submenu choices, shown below.
Select Chuck:
Touch Left to grind the left chuck.
Touch Right to grind the right chuck.
Touch Cancel to cancel the submenu.
Select Grind:
Touch Truing to select truing of the chuck.
Touch Dressing to select dressing of the chuck.
Touch Cancel to cancel the submenu.
Your selections will be displayed in the box located just above
the Start Cycle button.
Dress Wheel
Coarse
Fine
Cancel
Truing
Dressing
Cancel
Touch the Dress Wheel button to display the Select Wheel and
Select Grind submenu choices, shown below.
Select Wheel:
Touch Coarse to select the coarse grind wheel.
Touch Fine to select the fine grind wheel.
Touch Cancel to cancel the submenu.
Select Grind:
Touch Truing to select truing of the wheel.
Touch Dressing to select dressing of the wheel.
Touch Cancel to cancel the submenu.
Your selections will be displayed in the box located just above
the Start Cycle button.
Start
Cycle
Touch the Start Cycle button:
a. to begin the grinding/dressing cycle.
or
b. resume a cycle after a Pause.
