Operations and Maintenance Manual Operator Functions
Version 1.2 - June 2004 8 - 21
Stop
Cycle
Touch the Stop Cycle button:
a. when possible danger to people, product, or machine is
indicated. Touching the Stop button stops all machine
movement, turns all fluids off, and cancels the cycle. Power
stays on, and the computer screen continues to display.
Eliminate the problem before beginning a new cycle.
b. after a completed cycle to turn off the flashing Stop Cycle
button which indicates to the operator that the cycle has been
completed.
Help
Touch the Help button to display information on making
selections at the Dress Cycle menu.
SHOW
RECIPE
HIDE
RECIPE
Touch the Show Recipe button to display the parameters of the
recipe you have entered. Compare the displayed parameters
against the desired parameters.
Note: If the parameters require a change, refer to the Machine
Setup chapter of this manual or to your process supervisor.
Touch the Hide Recipe button to hide the displayed parameters.
Note: The cassette turrets do not rotate at the Dress Cycle menu while the cycle is
running.
Information Available at the Dress Cycle Menu
The Status Display Area
The real time status display, located at the right side of the Dress Cycle menu screen,
monitors machine component position and function values continuously while machine
power is on. The Dress Cycle status display is identical to that of the Home Machine
menu. For details, refer to Information Available at the Home Machine Menu, located
in the Menus Used in Basic Operation section of this chapter.
Error Messages
Fault (error) messages indicating errors that prevent cycle function are displayed when
appropriate. For detailed information on error messages refer to the Troubleshooting
chapter of this manual.
