S6F20 * H<-E
<L> .
6.79 S6F21 - Request Annotated Report Request
S6F21 W * H->E
<U4 RPTID> . * Report ID
The Host requests an Annotated Report for the specified RPTID.
6.80 S6F22 - Request Annotated Report Data
S6F22 * H<-E, Multiblock
<L
<L [2]
<U4 VID> * VID - Variable ID
<V>
>
...
> .
The Equipment sends the Annotated Report.
If no Report is defined for the RPTID in S6F21, S6F22 has the following special error format:S6F22 *
H<-E
<L> .
6.81 S6F23 - Request Spooled Data
S6F23 W * H -> E
<U1 RSDC> .
The Host sends this message to start the transfer of spooled messages from the Equipment to the Host, or to delete the
contents of the spool file, depending on the value of RSDC.
When the Host requests the spooled messages (RSDC is zero), the Equipment will send messages according to EC
"MaxSpoolTransmit". All messages are sent from oldest to newest, and once the message is successfully sent, it is
removed from the spool. If MaxSpoolTransmit is zero, all messages will be sent one at a time until the last message has
been delivered. If MaxSpoolTransmit is set to a non-zero value, the Equipment will send the lesser of MaxSpoolTransmit
or messages left in spool. If in this case the Equipment sends MaxSpoolTransmit messages, and messages remain in the
spool, the Equipment will wait for another S6F23 to deliver the next messages.
If the Host sends S6F23 with RSDC set to one, this will be interpreted by the Equipment as a request to purge the spool.
RSDC Description
0 Transmit spooled messages.
1 Purge spooled messages
6.82 S6F24 - Request Spooled Data Acknowledge
S6F24 * H <- E
<B [1] RSDA> .
Equipment acknowledges the Host's request to either purge spooled messages or send spooled messages to the Host.
RSDA Description
0x00
Normal. Equipment will start to send spooled data or
optionally purge the spool. Action performed will
