STRASBAUGH, INC.
7AF SECS/GEM Interface Ver. 1.9 February 19, 2002 6-39
Strasbaugh Confidential
6-39
6.93 S9F1 - Unrecognized Device ID
S9F1 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6.94 S9F3 - Unrecognized Stream
S9F3 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6.95 S9F5 - Unrecognized Function
S9F5 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6.96 S9F7 Invalid Data
S9F7 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6.97 S9F9 Transaction Timer Timeout
S9F9 * H<-E
<B [10] SHEAD> . * SHEAD - Stored Header
6.98 S9F11 - Data Too Long
S9F11 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6.99 S10F1 - Terminal Request
S10F1 [W] * H<-E
<L [2]
<B [1] TID> * Terminal ID
<A [160] TEXT> * Message Text
> .
The Equipment sends text to the Host. This Equipment may send the following values for TID:
TID Description
0x00 Always sent.
Equipment Constant "WBitS10" controls whether the Equipment sends S10F1 with W-Bit "1" (Reply Expected) or "0"
(No Reply Expected).
6.100 S10F2 - Terminal Request Acknowledge
S10F2 * H->E
<B [1] ACKC10> . * Acknowledge Code
The Host may send the following values for ACKC10:
ACKC10 Description
0x00 Normal. Host accepts the S10F1.
Other Host rejects the S10F1.
