events as they occur.
7.2.2 Equipment Reports Event
Step
SECS Message
Description
1.
The Equipment recognizes that an event has occurred. The Host has enabled
reporting for the CEID, and possibly has defined one or more Reports and
linked them to the CEID. The Equipment Constant RpType is set to "False",
requesting normal reports.
2.
H <- E S6F5 W
Inquire. If S6F13 will be multi-block, the Equipment first sends this Inquire
to request permission. If S6F11 is single-block, skip this and the next step.
3.
H -> E S6F6
Grant. The Host grants permission to send multi-block event report. If
GRANT6 is non-zero, this scenario fails here, and the event data is discarded.
4. H <- E S6F11 W The Equipment sends Event reports for the CEID that occurred
5. H -> E S6F12 The Host acknowledges the report.
7.2.3 Equipment Reports Annotated Event
Step
SECS Message
Description
1.
The Equipment recognizes that an event has occurred. The Host has enabled
reporting for the CEID, and possibly has defined one or more Reports and
linked them to the CEID. The Equipment Constant RpType is set to "True",
requesting Annotated reports.
2.
H <- E S6F5 W
Inquire. If S6F13 will be multi-block, the Equipment first sends this Inquire
to request permission. If S6F13 is single-block, skip this and the next step.
3.
H -> E S6F6
Grant. The Host grants permission to send multi-block event report. If
GRANT6 is non-zero, this scenario fails here, and the event data is discarded.
4. H <- E S6F13 W The Equipment sends annotated event reports for the CEID that occurred.
5. H -> E S6F14 The Host acknowledges the report.
Note: In all other scenarios in which event reports occur, the Events or Annotated Events are shown in abbreviated form
(S6F11/S6F12 only). The complete Event Report Scenarios are shown here.
7.2.4 Host Initiates Trace
Step SECS Message Description
1. H -> E S2F23 W The Host initiates a trace.
2. H <- E S2F24 The Equipment acknowledges the trace request. If the data in S2F23 is not
valid, the acknowledge code in this message is non-zero and the scenario
ends. Otherwise, the following steps are done "TOTSMP" times, where
TOTSMP is the total number of samples to be done.
3.
The Equipment waits "DSPER" (data sample period). While waiting, the
Equipment continues to operate normally, responding to any SECS messages
that may be received, etc. After the wait is finished, the values of the
variable(s) to be traced are obtained and saved. If "REPGSZ" samples have
been saved, or if this is the last sample, do the following steps.
4. H <- E S6F1 W The Equipment sends trace data.
5. H -> E S6F2 If the S6F1 has its W-bit set to 1, the Host acknowledges the trace data.
6.
If this is the last sample, the Equipment terminates this trace and the scenario
ends. Otherwise, go back to the beginning of step 3.
