7.2.5 Host Terminates Trace
Assumption: The Host started a Trace report as in the above scenario.
Step SECS Message Description
1.
H -> E S2F23 W
The Host initiates a trace, with the same trace ID as the currently running
trace, and with TOTSMP (number of samples) set to "0".
2.
H <- E S2F24
The Equipment acknowledges the trace request. If the data in S2F23 is valid,
the Equipment terminates the trace.
3.
If the Equipment has saved trace data that has not yet been sent to the Host, it
discards the saved data.
7.2.6 Host Requests Status
Step SECS Message Description
1. H -> E S1F3 W Discrete Variable Request. The Host requests the VIDs of interest.
2. H <- E S1F4 The Equipment sends the Variable values.
7.2.7 Host Defines Limits
Step SECS Message Description
1. H -> E S2F45 W Host defines new variable limits attributes.
2.
H <- E S2F46
Equipment accepts new limits definitions, and responds with VLAACK =
0x00.
7.2.8 Host Queries Defined Limits
Step
SECS Message
Description
1.
H -> E S2F47 W
Host requests listing of defined limits. This request may be for limits of
individual variables listed in this message, or if this message is an empty list,
all limits will be replied.
2. H <- E S2F48 Equipment sends limits values as required.
7.2.9 Host Requests Report by CEID
Step SECS Message Description
1.
H -> E S6F15 W
Request Event Report. The Host requests a report for the specified CEID. In
this way, the host requests the Equipment to "pretend that the specified CEID
has occurred.
2. H <- E S6F16 The Equipment sends reports linked to that CEID.
7.2.10 Host Requests Annotated Report by CEID
Step SECS Message Description
1.
H -> E S6F17 W
Request Annotated Event Report. The Host requests a report for the specified
CEID. In this way, the host requests the Equipment to "pretend" that the
specified CEID has occurred.
2. H <- E S6F18 The Equipment sends annotated reports linked to that CEID.
7.2.11 Host Requests Report by RPTID
Step SECS Message Description
1. H -> E S6F19 W Request Report. The Host requests a report for the specified RPTID.
