2. H <- E S6F20 The Equipment sends the report.
7.2.12 Host Requests Annotated Report by RPTID
Step SECS Message Description
1.
H -> E S6F21 W
Request Annotated Report. The Host requests an annotated report for the
specified RPTID.
2. H <- E S6F22 The Equipment sends the annotated report.
7.2.13 Are You There
Step SECS Message Description
1. H -> E S1F1 W Are You There. The Host sends this simple message.
2. H <- E S1F2 The Equipment reports its MDLN and SOFTREV.
7.2.14 Host Reads Equipment Constants
Step SECS Message Description
1. H -> E S2F13 W Host requests the values of one or more Equipment Constants.
2. H <- E S2F14 The Equipment responds with the values of the requested Equipment
Constants.
7.2.15 Host Sets Equipment Constants
Step SECS Message Description
1. H -> E S2F15 W Host sends new values for one or more Equipment Constants.
2.
H <- E S2F16
If all new values are valid, the Equipment saves the new values and sends this
message with an acknowledge code of "0". If one or more new values are not
valid, no Equipment Constants are changed and the acknowledge code in this
message is non-zero.
7.3 Alarms
7.3.1 Equipment Reports Alarm
Step
SECS Message
Description
1.
H <- E S5F1 [W]
If reporting for this alarm ID is disabled, skip this and the following step.
Otherwise send the alarm. The Equipment Constant WBitS5 determines
whether the W- bit is 0 or 1 in this message.
2.
H -> E S5F2
If the W-bit in S5F1 is 1, the Host acknowledges the alarm report. Otherwise,
skip this step.
3.
H <- E S6F11 W
If the event ID associated with this alarm state is enabled, send the event
report. Otherwise, the scenario ends.
4. H -> E S6F12 The Host acknowledges the event report.
7.3.2 Host Enables/Disables Alarms
Step SECS Message Description
1. H -> E S5F3 [W] The Host specifies ALIDs to be enabled or disabled.
2. H <- E S5F4 If the W-bit in S5F3 is 1, the Equipment acknowledges.
