STRASBAUGH, INC.
7-10 February 19, 2002 7AF SECS/GEM Interface Ver. 1.9
Strasbaugh Confidential
7.5.6 Host Requests Directory
Step SECS Message Description
1.
H -> E S7F19 W
Host requests the names (PPIDs) of all Process Programs that are stored in
the Equipment's Process Program library.
2. H <- E S7F20 The Equipment replies with the list of PPIDs.
7.5.7 Operator Changes Process Program Library
Step SECS Message Description
1.
The Equipment Operator creates, changes, or deletes a Process Program in the
Library.
2.
H <- E S6F11 W
The Equipment sets PPCHANGESTATUS to "Create", "Change", or
"Delete", as appropriate, sets
PPCHANGENAME, and signals CEID GemPPChangeEvent. Event Reports
as appropriate.
3. H -> E S6F12 The Host acknowledges the report.
7.6 Equipment Terminal Communications
7.6.1 Host to Equipment, Single Line
Step SECS Message Description
1. The Host has data to display at the Equipment's front panel.
2.
H -> E S10F3 [W]
Terminal Display. The Host sends text. The Equipment displays the text on
its front panel.
3. H <- E S10F4 If the W-bit in S10F3 is 1, the Equipment acknowledges.
4. The Operator acknowledges that he/she has read the message.
5. H <- E S6F11 W The Equipment signals CEID S10Ack. Event Reports as appropriate.
6. H -> E S6F12 The Host acknowledges the report.
7.6.2 Host to Equipment, Multi-Line
Step SECS Message Description
1. The Host has a multi-line data to display at the Equipment front panel.
2.
H -> E S10F5 [W]
Terminal Display Multiple. The Host sends text. The Equipment displays the
text on its front panel.
3. H <- E S10F6 If W-bit in S10F5 is 1, the Equipment acknowledges.
4. The Operator acknowledges that he/she has read the message.
5. H <- E S10F11 W The Equipment signals CEID HostMsgAck. Event Reports as appropriate.
6. H -> E S6F12 The Host acknowledges the report.
7.6.3 Equipment Sends Text to Host
Step SECS Message Description
1. The Equipment operator enters data to send to the Host.
2.
H <- E S10F1 [W]
Equipment sends text to Host. The W-bit in this message may be either 0 or
1. The Host displays the message for the operator.
3. H -> E S10F2 If the W-bit in S10F1 is 1, the Host acknowledges the text message.
