7.5.3 Unformatted, Equipment-Initiated Download
Step SECS Message Description
1. H <- E S7F5 W Equipment requests a Process Program.
2.
H -> E S7F6
The Host sends the Process Program. If the Process Program is valid, the
Equipment stores the Process Program in its library, and the scenario ends. If
the data portion of S7F6 is an empty list, or if the Process Program is not
valid, the Equipment does not store it in its library and the scenario continues.
3.
H <- E S6F11 W
The Equipment sets "PPCHANGENAME" to the requested PPID and signals
CEID GemBadDownloadEvent. Event reports as appropriate.
4. H -> E S6F12 The Host acknowledges the report.
7.5.4 Unformatted, Equipment-Initiated Upload
Step SECS Message Description
1.
H <- E S7F1 W
Process Program Inquire. If S7F3 is multi-block, the Equipment requests
permission to send a multi-block message. If S7F3 is single-block, skip this
and the following step.
2.
H -> E S7F2
Process Program Grant. The Host grants permission. If PPGNT is non-zero,
the scenario fails here.
3. H <- E S7F3 W Send Process Program. The Equipment uploads Process Program to Host.
4. H -> E S7F4 The Host acknowledges. The Equipment ignores ACKC7.
7.5.5 Host Deletes Process Program
Step SECS Message Description
1.
H -> E S7F17 W
Host sends a request to delete one or more Process Programs from the
Equipment's library of Process Programs.
2.
H <- E S7F18
The Equipment replies with an acknowledge code. If all specified Process
Program(s) were deleted successfully, the acknowledge code is 0. If one or
more of the specified Process Programs could not be deleted, the
acknowledge code is non-zero.
