Strasbaugh nTellect (Model 7AF) Wafer Grinder
8 - 56 Version 1.2 - June 2004
GRIND WHEEL DRESSING AND TRUING
SELECT THE WHEEL AND THE TREATMENT DESIRED
For the procedure below, we will use dressing the coarse grind wheel as our example.
To dress the fine grind wheel or true either the coarse or fine grind wheel, make the
desired selections when the Select Wheel and Select Grind submenus are displayed.
Operator Action Explanation/Screen Display
3. Dress Wheel At the Dress Cycle menu, touch the "Dress
Wheel" button to display the Select Wheel
submenu.
4. Coarse At the Select Wheel submenu, touch the name of
the wheel (coarse or fine) to be dressed. For our
example, touch "Coarse" to select the coarse
wheel.
5. Dressing Touch the "Dressing" button at the Select Grind
submenu to select dressing.
To Next Page
