Operations and Maintenance Manual Operator Functions
Version 1.2 - June 2004 8 - 57
COMPARE THE STORED RECIPE VALUES WITH THE PARAMETER VALUES RECEIVED FROM
THE PROCESS SUPERVISOR
Operator Action Explanation/Screen Display
6. SHOW RECIPE Touch the "SHOW RECIPE" button to display
the Show Recipe submenu.
Note: The selections you have made (Wheel, Coarse, Dressing) will now be
displayed in the boxes located just above the Stop Cycle button.
Figure 8-12 Example of a Coarse Wheel Dressing Recipe
Step 1 Step 2 Dwell Lift
Coarse
Wheel
RPM
1875
Removal
40 10 75 revs.
20 µm
Feed rate
2 1 @ 2 µm/sec.
Chuck
Speed
150 150 150 150 RPM
Figure 8-13 Example of a Fine Wheel Dressing Recipe
Step 1 Step 2 Dwell Lift
Fine
Wheel
RPM
4350
Removal
40 10 75 revs.
20 µm
Feed rate
2 1 @ 2 µm/sec.
Chuck
Speed
150 150 150 150 RPM
