Operations and Maintenance Manual Operator Functions
Version 1.2 - June 2004 8 - 65
WHILE THE CYCLE IS RUNNING, MONITOR THE STATUS SCREEN DISPLAY VALUES
10. While the cycle is running, monitor the real time display and compare with
the following requirements:
a. The force during dressing should remain steady and should not rise
above 10 lbs. If the force fluctuates erratically (by more than 10 lbs),
the wheel probably needs to be changed.
b. The motor current during dressing should be within normal operating
limits (less than 9.0 amps).
c. During the dwell portion of the chuck grinding sequence, the probe
fluctuation should be less than 1 micron.
If any of the above requirements is not met:
• STOP the cycle by following the procedures shown in If There’s a
Problem, Stop (Cancel) the Cycle, immediately below.
Correct the problem before continuing by referring to Normal
Operating Conditions and Strategies for Maintaining Them, located in
the Troubleshooting chapter of this manual.
If the status screen value requirements are met:
• Skip to When the Start Cycle and Stop Cycle Button Begin to Flash,
below.
