Pamux User’s Guide 47
DC Input Modules AC Input Modules
G4IAC5 G4IAC5
G4IAC5A G4IAC5A
G4IAC5MA G4IAC5MA
G4IDC5 G4IDC5
G4IDC5B G4IDC5G
G4IDC5D G4IDC5MA
G4IDC5G IAC5
G4IDC5K IAC5A
G4IDC5MA IDC5
IDC5 IDC5G
IDC5B SNAPIAC5
IDC5D SNAPIAC5A
IDC5G - - -
IAC5 - - -
IAC5A - - -
SNAPIDC5 - - -
Figure 2-31: Wiring for DC and AC Input/Output Modules
