Operations and Maintenance Manual Machine Setup
Version 1.2 - June 2004 9 - 25
GRIND WHEEL EXAMPLE RECIPES
Grind Wheel Dressing
Example of a Coarse Wheel Dressing Recipe
Step
1
Step
2
Dwell
Lift
Coarse Wheel
RPM
1875
Removal
40 10 75
revs.
20 µm
Feed rate
2 1 @ 2 µm/sec.
Chuck Speed
150 150 150 150 RPM
Example of a Fine Wheel Dressing Recipe
Step
1
Step
2
Dwell
Lift
Fine Wheel
RPM
4350
Removal
40 10 75
revs.
20 µm
Feed rate
2 1 @ 2 µm/sec.
Chuck Speed
150 150 150 150 RPM
Grind Wheel Truing
Example of a Coarse Wheel Truing Recipe
Step
1
Step
2
Dwell
Lift
Coarse Wheel
RPM
1875
Removal
190 10 75
revs.
20 µm
Feed rate
2 1 @ 2 µm/sec.
Chuck Speed
150 150 150 150 RPM
Example of a Fine Wheel Truing Recipe
Step
1
Step
2
Dwell
Lift
Fine Wheel
RPM
4350
Removal
190 10 75
revs.
20 µm
Feed rate
2 1 @ 2 µm/sec.
Chuck Speed
150 150 150 150 RPM
WORK CHUCK EXAMPLE RECIPES
Notes:
One chuck dressing recipe is stored and used for both work chucks.
