Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 45
b. Using a 3/4-in. open end wrench, rotate the screw as needed to meet the
goal.
Rotating the screw clockwise lowers the side of the spindle nearest the left
side of the machine.
Rotating the screw counterclockwise raises the side of the spindle nearest
the left side of the machine.
Front to Rear
c. Locate the lower left spindle front to rear adjusting screw, a wedge
assembly extending vertically from the bottom of the lower left spindle
assembly.
Notes:
Access the adjusting screw through the door 14 opening.
The screw is labeled for easy identification.
d. Using a 9/16-in. open end wrench or a 1/4-in. hex key, rotate the screw as
needed to meet the goal.
Viewing the screw from the bottom of the machine, rotating the screw
counterclockwise lowers the back of the spindle.
