Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 57
5. At the Machine Maintenance menu, carefully move the bridge to the left until
the hard stop spring cushion is compressed one-half inch:
GOAL: Watching carefully and moving slowly, move the bridge
until the spring cushion is compressed one-half inch (one-
half stroke).
Note: As there is no way to measure the one-half inch of compression,
a visual judgment must be made here.
Touch to Select Explanation/Screen Display
a. Factor x 10
or
Factor x 1 Estimate the distance the bridge must move and
set the factor.
As the bridge nears the sensor, reduce the factor
as needed to move the bridge in smaller
increments.
b. ⇐ Touch the "Left Arrow" button on the bridge
icon at the top of the screen as many times as
needed to position the bridge to meet the goal.
