Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 61
VIII. SPINDLE Z TRAVEL PROXIMITY SENSOR ADJUSTMENTS
Notes:
The upper sensor for each spindle is the home sensor.
Both sensors are mounted horizontally.
A. BEFORE YOU BEGIN
Tools Required
• feeler gauge
• adjustable wrench
• six-inch scale
Confirm that Compressed Air Is ON
Follow the procedures detailed in the Operator Functions chapter of this manual.
Turn Machine Power ON
Follow the procedures detailed in the Operator Functions chapter of this manual.
B. CHECK PRESENT CALIBRATION AND ADJUST
