IX. WHEN THE GRINDING AREA INITIAL ADJUSTMENTS HAVE
BEEN SUCCESSFULLY COMPLETED
Tools Required
• 5/32-in. hex key
• 3/16-in. hex key
1. Reinstall the probes on their support arms:
a. Using a 3/16-in hex key, remove the probe fixtures from the grinding wheel
backing plates.
b. Using a 5/32-in. hex key, remove the probes from the probe fixtures.
c. Using a 5/32-in. hex key, remount the probes to their support arms using
two 10-32 x 1 1/2 socket head capscrews to secure each probe.
d. Pull the excess black power cable and vacuum tubing down out of the way.
2. Using a 3/16-in. hex key, remove the fringe plates and spring washer pairs.
3. If the work chucks were installed when you began, reinstall them:
• Using a 3/16-in. hex key, reinstall the work chuck assemblies on the lower
spindles, securing each with the four accompanying 1/4-20 x 1/2 long
screws.
4. Go on to the Handling Area Initial Adjustments.
