Strasbaugh nTellect (Model 7AF) Wafer Grinder
11 - 128 Version 1.2 - June 2004
2. Position the bridge as needed.
• To change the left work chuck, move the bridge to its right
position.
• To change the right work chuck, move the bridge to its left
position.
For our example, we will change the right work chuck.
At the Machine Maintenance menu, move the bridge to its left position:
Touch to Select Explanation/Screen Display
a. Machine Maint At the Main Menu screen, touch the "Machine
Maint" button to select the "Machine
Maintenance menu.
Displays:
Machine Maintenance menu
b. L Touch the "L" button, located at the upper left
of the menu screen, to move the bridge to its left
position.
(R = right)
3. Open the front of the machine:
Note: Steps a. through g., immediately below, separate the handling
section of the machine from the grinding section.
a. Turn machine power OFF.
b. Remove door 17.
