Strasbaugh nTellect (Model 7AF) Wafer Grinder
11 - 136 Version 1.2 - June 2004
Touch to Select Explanation/Screen Display
a. Home Machine At the Main Menu screen, touch the "Home
Machine" button to select the Home Machine
menu.
Displays:
Home menu
b. Reference Left
Probe At the Home Machine menu, touch the
"Reference Left Probe" button to reference the
left probe.
c. Measure
Thickness Touch the "Measure Thickness" button until the
left probe is in up position.
d. Reference Right
Probe At the Home Machine menu, touch the
"Reference Right Probe" button to reference the
right probe.
e. Measure
Thickness Touch the "Measure Thickness" button until the
right probe is in up position.
