Operations and Maintenance Manual Mechanical Maintenance Procedures
Version 1.2 - June 2004 11 - 149
CASSETTE TURRETS
ROTARY ACTUATOR SENSOR LOAD/ROBOT POSITION
ADJUSTMENTS
Notes:
In robot position the cassette turret faces the robot.
In load position the cassette turret faces the operator.
A. BEFORE YOU BEGIN
Tools Required
• flathead screwdriver
Confirm that Compressed Air Is ON
Follow the procedures detailed in the Operator Functions chapter of this manual.
Power Up the Machine
Follow the procedures detailed in the Operator Functions chapter of this manual.
