Effects of Using the Factor Buttons
The chart below shows the resulting movement sizes and speed adjustments for each
combination of component function unit and factor.
FACTOR
FUNCTION
x 1 x 10 x 100 x 1000
Bridge Travel 0.001 inches 0.01 inches 0.1 inches 1.0 inches
Spindles Up/Down 0.1 microns 1.0 microns 10.0
microns
100.0
microns
Spindle Speed
Adjustment
+ / - 1
RPM
+ / - 10
RPM
+ / - 100
RPM
+ / - 1000
RPM
Chuck Speed
Adjustment
+ / - 1
RPM
+ / - 10
RPM
+ / - 100
RPM
+ / - 1000
RPM
