Operations and Maintenance Manual Software Calibration
Version 1.2 - June 2004 12 - 15
Touch to Select Explanation/Screen Display
2. Factor x 1000 Estimate the distance the bridge must move and set
the factor. For example, touch the "Factor x 1000"
button to set the factor at .001 inches x 1000.
Notes:
.001 inches x 1000 = one inch of movement per touch
of the Right or Left Arrow button touch.
Readjust the factor, as shown below in Step 4., to
avoid overtraveling and touching the sensor.
3. ⇒ Touch the "Right Arrow" button on the bridge icon at
the top of the screen as many times as needed to have
the bridge approach the sensor.
4. Factor x 10
or
Factor x 1 As the bridge nears the sensor, reduce the factor as
needed to move the bridge in smaller increments.
5. ⇒ Touch the "Right Arrow" button on the bridge icon at
the top of the screen as many times as needed to
position the bridge to meet the goal.
You may now select another assembly icon, one of the other menu buttons, or
the QUIT button to return to the Main Menu.
