Strasbaugh nTellect (Model 7AF) Wafer Grinder
12 - 16 Version 1.2 - June 2004
OUTPUT CONTROL / INPUT STATUS MENU
The Output Control/Input Status menu, selected at the Machine Maintenance menu,
displays the current state of the machine inputs and permits the outputs for each of the
machine functions to be forced on and off. The outputs are grouped according to
machine function and accessed by pressing the corresponding icon.
Follow the procedure below to display the Output Control/Input Status menu:
Operator Action Explanation/Screen Display
1. Machine
Maint At the Main Menu screen, touch the "Machine
Maint" button to select the Machine Maintenance
menu.
The screen displays the Machine Maintenance menu.
2. Inputs/
Outputs At the Machine Maintenance menu screen, touch the
"Inputs/Outputs" button to select the Output
Control/Input Status menu.
The screen displays the Output Control/Input Status
menu, shown below.
