Strasbaugh nTellect (Model 7AF) Wafer Grinder
12 - 26 Version 1.2 - June 2004
MACHINE (CALIBRATION) SETUP ENTRY MENU
WARNING! If set incorrectly, the parameters at the Machine Setup Entry
menu may render the machine inoperable, damage the
product, or damage the machine.
Calibration variable values should be altered only by a trained
service technician or process engineer.
Types of Parameters Stored at the Machine Setup Entry Menu
At the Machine (Calibration) Setup Entry menu, the values of calibration variables
common to all grind recipes are stored, displayed and changed.
Parameters which can be changed from recipe to recipe are addressed in the Machine
Setup chapter of this manual.
Touch Screen Display of Variable Values
Variable values can be displayed using the touch screen.
Keyboard Changing of Variable Values
Variable values can be changed only by using the control computer keyboard supplied
with the 7AF to enter new values. (See the Physical Description chapter of this
manual for information on attaching the keyboard.)
List of Calibration Variables
Refer to Appendix A of this manual for the 7AF Calibration Variables Listings. A
printed list of the calibration variables stored at the Machine Setup Entry menu,
together with some descriptive notes, is available at that location.
Follow the procedure below to display the Machine Setup Entry menu:
