Strasbaugh nTellect (Model 7AF) Wafer Grinder
13 - 18 Version 1.2 - June 2004
SEND 2 CASSETTE TURRET ROTARY ACTUATOR
Solenoid
No.
Component Name
Location/
Drawing No.
Setting Goals
15A
and
15B
Send 2 Cassette Turret
Rotary Actuator
Regulators and
Gauges: Door 7
Panel
Flow Control: At
the cylinder, located
inside a small drip
pan at the top of the
machine cabinet,
inside door 8.
Drawing: 224039
Pressure: 50 PSI
Flow Control: Set to
produce smooth,
steady movement of
the cylinder.
Procedure for Setting Pressure and Flow Control:
CAUTION! To prevent injury or a crash, before exercising the cylinder, make
sure all objects, including your hands are clear of the cylinder.
• Repeat as for Send 1 cassette, substituting Send 2 for Send 1 where
appropriate.
