Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 17
3. Observe motion while the cylinder exercises:
WARNING: AVOID PINCH POINTS WHILE SETTING THE
FLOW CONTROL!
GOAL: Set the flow control to produce smooth, steady movement of
the cylinder.
4. Remove the drip pan, exposing the flow control.
5. Using a flatblade screwdriver, set the flow control as needed to meet the goal.
6. Test the adjustment by repeating Steps 2c., 2d., 3., and 5, immediately above.
Repeat testing and adjusting until the goal is met.
7. Replace the drip pan.
