Strasbaugh nTellect (Model 7AF)Wafer Grinder
2 - 10 Version 1.2 - June 2004
A. GRINDING AREA CABINET BASE LEVELING PROCEDURE
Tools Required
• standard bubble level
• 15/16-in. open end wrench
• 3/8-in. open end wrench
LEVELING FEET
The grinding section of the machine has four leveling feet.
The leveling feet can be raised or lowered by turning the hex head adjustment bolt
above each foot after loosening the locking nut.
Each leveling foot should be individually adjusted such that together they contact the
floor with the machine's weight evenly distributed over all four feet.
LEVELING PROCEDURE
Follow the steps below to level the grinding section:
1. Remove doors 14 and 17.
2. Slightly loosen the two wing nuts that secure the grinding section of the
machine to the handling section:
a. Inside the door 17 opening, locate the two fastening setscrew and wing nut
pairs.
b. Slightly loosen the two wing nuts by rotating them counterclockwise
manually.
