Operations and Maintenance Manual Installation
Version 1.2 - June 2004 2 - 11
Right Side
GOALS: (1) A bubble level reads LEVEL when placed (horizontally) on top of
the floor of the machine cabinet, inside door 17,
AND
(2) A bubble level reads PLUMB when placed (vertically) at the right
side front of the machine at the intersection of the top and bottom
machine cabinets.
3. Inside the door 17 opening, place a standard bubble level on top of the floor of
the machine cabinet, positioned with one end of the level pointing toward the
front of the machine and the other pointing toward the rear.
a. If the reading meets GOAL 1, skip to Step 5., below.
b. If the reading does not meet GOAL 1, go to Step 4, immediately below, to
correct the machine’s position.
4. Adjust the leveling feet until GOAL 1 (above) is met:
a. Using a 15/16-in. open end wrench, rotate the locking nut of each locking
nut and adjusting bolt pair counterclockwise to loosen.
b. Using a 3/8-in. open-end wrench, rotate each hex head adjusting bolt
counterclockwise or clockwise (up or down) as needed to meet GOAL 1.
c. Retighten the locking nuts by rotating them clockwise to firm.
