5. Move the bubble level to the right side exterior front of the machine,
positioning it vertically at the intersection of the top and bottom machine
cabinets.
a. If the reading meets GOAL 2, skip to Step 7., below.
b. If the reading does not meet GOAL 2, go to Step 6., immediately below, to
correct the machine’s position.
6. Adjust the leveling feet until GOAL 2 (above) is met:
a. Using a 15/16-in. open end wrench, rotate the locking nut of each locking
nut and adjusting bolt pair counterclockwise to loosen.
b. Using a 3/8-in. open-end wrench, rotate each hex head adjusting bolt
counterclockwise or clockwise (up or down) as needed to meet GOAL 2.
c. Retighten the locking nuts by rotating them clockwise to firm.
7. Recheck to confirm that GOALS 1 and 2 continue to be met:
a. Repeat Step 3., above.
b. If needed, repeat the adjustment procedure found in Step 4.
c. Repeat Step 5., above.
d. If needed, repeat the adjustment procedure found in Step 6.
e. Repeat checking and adjusting until both goals have been met.
f. When both GOAL 1 and GOAL 2 have been met, go on to Left Side,
below.
