Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 21
LEFT/RIGHT MEASUREMENT PROBES
Notes:
• The probe requires from 3 inches Hg to 6 inches Hg for lifting.
• Set the regulator of the SMC NZM Series vacuum ejector at 22 PSI incoming to
produce 5 inches Hg out.
• A single regulator and gauge provide control for both probes.
Solenoid
No.
Component Name
Location/
Drawing No.
Setting Goals
26
27
Left Measurement Probe
Right Measurement Probe
One Regulator and
One Gauge for both:
Mounted inside door
17 at the bottom left.
Drawing: 224018
Pressure: 22 PSI
Procedure:
• Rotate the knob on the regulator until the pressure gauge reads 22 PSI.
