Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 29
ROBOT FLIPPER
Solenoid
No.
Component Name
Location/
Drawing No.
Setting Goals
38
and
39
Robot Flipper
Note: Part No. 223518
Regulators and
Gauges: no gauge or
regulator; solenoids
located inside robot’s
head
2 Flow Controls:
Located on top of the
robot.
Drawing: 224019
Pressure: not
regulated
Flow Controls: Set to
produce smooth,
steady movement of
the cylinder.
Procedure for Setting Flow Controls:
Notes:
For detailed information on the robot’s hardware, software, and programming,
refer to the Equipe Technologies Atmospheric Robot, ATM - 100; Vacuum Robot,
VAC - 100, Technical Manual, located in Appendix G, Manufacturer’s
Documentation, of this (the Model 7AF Operation and Maintenance Manual)
manual.
When entering computer commands for the steps below, type the commands
exactly as they are shown in the left column, using the case (upper or lower)
shown.
