Operations and Maintenance Manual Pneumatic Adjustments
Version 1.2 - June 2004 13- 33
TURRET HYDRAULIC ACCUMULATOR RESERVOIRS
Notes:
• The hydraulic system for the four cassette turrets is powered by air pressure; the
oil in the four hydraulic reservoirs provides a dampener for smooth, steady
movement.
• The air pressure is controlled by one regulator and one gauge for the four turrets.
Solenoid
No.
Component Name
Location/
Drawing No.
Setting Goals
none
Cassette Turret Hydraulic
System
Note: 1 regulator and gauge
for both spindles.
Regulator and
Gauge: Inside door
8.
Drawing: 224002,
Sheet 1
Pressure: 20 PSI
Procedure:
• Turn the knob on the regulator until the pressure gauge reads 20 PSI.
