Strasbaugh nTellect 7AF - Page 537

Operations and Maintenance Manual Troubleshooting
Version 1.2 - June 2004 14 - 23
PROBES
LEFT PROBE
Cause: Probe not referenced. Resolution: Reference Probe.
NOTE: Bridge must not obstruct probe
from reaching chuck.
RIGHT PROBE
Cause: Probe not referenced. Resolution: Reference Probe.
NOTE: Bridge must not obstruct probe
from reaching chuck.
LEFT PROBE IS DOWN
Cause:
• Machine stopped with probe in down
position, preventing the bridge from
moving.
• Grind has aborted in the middle of
running.
Resolution:
• Raise the probe in the Machine
Maintenance screen on the GUI.
RIGHT PROBE IS DOWN
Cause:
• Machine stopped with probe in down
position, preventing the bridge from
moving.
• Grind has aborted in the middle of
running.
Resolution:
• Raise the probe in the Machine
Maintenance screen on the GUI.
