Studer D950 User Manual

D950 Digital Mixing System
3-26 Desk Operation SW V3.3 Date printed: 03.09.03
3.3.4.5 N–1 Output Parameters on the LACP
Example:
Available operating elements and their function
n-1_
LEVL
_OFF
AUTO
SW
1
AUTO
SW
2
AUTO
SW
3
AUTO
SW
4
n–1
TALK
21
LAST MODE43
PAGE
FREEZE
n–1 output control parameters
n–1 OUT ON/OFF
LEVEL
STAT key
Rotary encoder
LED bar
Center LED
Display
STAT key
Rotary encoder
LED bar
Center LED
Display
=
=
=
=
=
=
=
=
=
=
n–1 ON/OFF
no function
no function
no function
OFF: n–1 output off
ON: n–1 output on
no function
n–1 Out level
Bar display,
indicates current level
ON if level is set to 0 dB
LEVL; label of control parameter;
–20; indication of current level
not used not used
Display = Indication of selected parameter
(Pages 2 to 4 not used)
not used not used
