D950 Digital Mixing System
Date printed: 03.09.03 SW V3.3 Desk Operation 3-27
3.3.5 Mono AUX Section
On the channel strip, the channel signal can be routed to the mono AUX
busses 1 through 4 without having to access the LACP controls. In other
words, a dedicated set of ON/OFF controls for the mono AUX sends 1
through 4 are provided at the top of the channel strip. This routing can also
be accomplished using the Central Assign Unit.
Routing to the mono AUX busses 5 and above can only be performed via
the Central Assign Unit (CAU) or via the LACP page keys.
Mono AUX bus assignment is possible only on mono/stereo input chan-
nels, multitrack input/monitor channels, and group channels.
The available parameters for mono AUX are the following:
• Send level for all configured mono AUX channels (AUX 1 to max.)
• Pre-/after-fader position for all configured mono AUX channels
Note: The maximum number of mono AUX channels available via the channel
strip PAGE selectors is 16.
3.3.5.1 Assigning the Mono AUX Section
A. Global Assignment:
• Press MONO AUX on the Master Menu Selector.
The displays of all Channel Strips will switch over and indicate the
mono AUX control parameters, except those in FREEZE mode; see
chapter 3.3.2.
• Press one of the PAGE 1 through 4 keys on the MMS (PAGE 1 for
mono AUX 1 through AUX 4; PAGE 2 for mono AUX 5 through
AUX 8; and so on).
B. Local Assignment on the Channel Strip:
• Press ASN SEL; the ASN SEL key will flash.
• Press any AUX MONO selector key (AUX MONO 1 ON through
AUX MONO 4 ON).
ASN SEL + AUX MONO 1 ON (or AUX MONO 2, 3, or 4 ON):
The AUX 1 through AUX 4 parameters will be displayed on the LACP
PAGE 1.
• Press PAGE 2 on the LACP or MMS, and the AUX 5 through AUX 8
parameters will be displayed. PAGE 3 will display AUXs 9 through
12, and PAGE 4 will display AUXs 13 through 16.
C. Local Assignment affecting all Channel Strips:
• Press LINK ACCESS on the Master Menu Selector.
• Pressing a local assignment key will now affect all Channel Strips. The
same functions as described in “B” are available.
D. Local Assignment with Auto Assign Modes "In-Only":
• Press AUTO ASSIGN MODES on the Master Menu Selector once
(AUTO ASSIGN MODES is illuminated).
• Pressing one of the AUX MONO keys on the channel strip will assign
the MONO AUX parameters to the LACP without pressing the ASN
SEL key, provided the function toggles to an IN (or ON) status. If it
toggles to an OUT (or OFF) status, the knob status does not change.
EQ
3
ON
1
ON
3
ON
1
ON
4
ON
2
ON
4
ON
2
ON
AUX
MONO
GEN
IN 2
IN 1
INPUT DIR OUT
ON
Input
Busses
Meters
Out
PROCESSING
FILT
AUX
STEREO
MENU
EQ2
INPUT
OUT/
N-1
EQ FILTER
COMP GATE
EXP/LIM/
INSERT DELAY
MONO
AUX
ADD.
AUX
STEREO
AUX
PAN
PAGE
1
PAGE
3
SHOW
VALUES
FREEZE
OFF
LINK
ACCESS
MODES
ASSIGN
AUTO
4
PAGE
PAGE
2
