D950/Vista Digital Mixing System
4-72 GC Operation SW V3.3 Date printed: 05.08.03
4.4.7.1.4 Useful Information
• Any DSP Channel can be assigned to any Channel Strip on the virtual
control surface.
• Any DSP Channel can be assigned more than once to several different
Channel Strips on any Section.
• It is not necessary to assign all DSP Channels available in the loaded con-
figuration; however, there will be no control of these channels from the
control surface.
• Assigning DSP Channels to Channel Strips has no affect on audio. It is
purely a viewing function, and therefore changing the strip setup can be
done at any time whilst operating the console.
• An indication is provided to highlight which bays are currently displayed
on the physical console. These displayed bays are in dark gray.
4.4.7.1.5 Labels in Strip Setup
The most useful label type to show in strip setup is the “Inherited Label”.
This is the session label of the source that is patched to a DSP channel and
also relates to the large label in the channel strip display. See chapter
4.4.2.6 for more information regarding the Vista labeling system. For this
reason, a checkbox is provided which locks the label type view of Strip
Setup to show the “Inherited labels” (see below). Check the “Show Inher-
ited Labels” box to always show Inherited Labels in the Strip Setup win-
dow.
If the “Show Inherited Labels” box is not checked, the label type shown in
the Strip Setup will follow the choice of label which is displayed by the
smaller label in the Channel Strips. See chapter 4.4.2.6.2 for a description
of this label.
Show Inherited Labels
