D950/Vista Digital Mixing System
4-98 GC Operation SW V3.3 Date printed: 05.08.03
Reference Type Once the Sync Reference has been selected, the type can be set here, se-
lecting from:
Reference type Select from
Internal/Reader: TC Input Internal
Video
PAL
NTSC half picture
NTSC full picture
NTSC drop frame
Double bi-phase
Double bi-phase
Ami phase
Move Clock
Move Clock 16 (pulses per second)
Move Clock 32 (pulses per second)
Move Clock 64 (pulses per second)
Move Clock For the move clock input, the clock rate can be set to predefined values of
16, 32 or 64 (see above), or it can be adjusted using the slider or by enter-
ing numerical values. The range is 1 through 2048 pulses per second.
4.6.5.2.4 TC3 Generator Settings
The GENERATOR settings have to be set according to the desired time
code format to be generated. Set the TC reader settings to “TC Input or
Internal Generator” in order to activate the TC3 generator as your time-
code source. The settings are:
Frame Rate: Select from 24/25/30/30 drop frame formats for the generated TC signal.
Note: The TC3 internal generator has no ability to jog/shuttle nor fast rewind or
forward.
4.6.5.2.5 Machine Control Settings
For information on machine control settings please refer to chapter
4.5.2.1.1.
